Bright Side of the News has a cost analysis breakdown on the GF100 (Fermi) chip. According to the article, the GF100 is being manufactured at TSMC on a 300mm wafer using a 4540 nm process. Assuming that the GF100 chip is the same size as the GT200 chip, which was manufactured on a 65 nm process, then 94 GF100 chips will fit on a wafer. If one assumes a 40% yield, that gives Nvidia 37~38 chips per wafer. At $5000 per wafer, that means that a GF100 chip costs $131. How much is AMD paying per chip? From the article:

… the current cost of single AMD Cypress die is $96. For as long as you’re under $100 per die, you can count your blessings with TSMC’s 40nm process. Reality is that AMD can easily reach 60-70% yields with Cypress and they will drive the cost of a single Cypress ASIC to anywhere between $54-64 [70 to 60% yield]. Thus, cost advantage AMD, no matter what happens.

The article is really worth reading, as it deals with the 2% yield rumor for the A1 silicon, and talks about the yields for the A2 silicon.

via Bright Side of the News : nVidia GF100 Fermi silicon cost analysis
